description: <h1 id="style-of-patent-drawing-8921xy3b8">style of Patent drawing</h1><p></p><p>A patent drawing is a technical illustration that accompanies a patent application to visually depict an invention or a specific aspect of it. These drawings serve as a visual representation of the invention and provide additional clarity and detail to the written description.</p><p>Patent drawings are required to meet certain standards set by the patent office. They must be clear, concise, and in black and white. The drawings should accurately depict the invention from various angles and show all the necessary components and features.</p><p>The purpose of patent drawings is to provide a visual understanding of the invention, especially when the written description may not fully convey all the details. They help examiners, inventors, and the public to better comprehend the invention's structure, function, and overall design.</p><p>Patent drawings can be created by the inventor or by a professional illustrator familiar with the guidelines and requirements of the patent office. They play a crucial role in the patent application process, as they contribute to the overall understanding and assessment of the invention's novelty, usefulness, and potential for patentability.</p><p>专利图是附带在专利申请中的技术插图，用于视觉上描述发明或其特定方面。这些图纸作为发明的视觉表现，为书面描述提供了额外的清晰度和细节。</p><p>专利图必须符合专利局规定的一定标准。它们必须清晰、简洁，并且是黑白色调。图纸应准确地从不同角度描绘发明，并显示所有必要的组件和特征。</p><p>专利图的目的是在书面描述可能无法完全传达所有细节时，提供对发明的视觉理解。它们有助于审查员、发明者和公众更好地理解发明的结构、功能和整体设计。</p><p>专利图可以由发明者或熟悉专利局指南和要求的专业插图师创建。它们在专利申请过程中起着关键作用，因为它们有助于对发明的新颖性、实用性和专利可行性的整体理解和评估。</p>
