--- datasets: - Borcherding/GradientMagnitude2CoralReef_Annotations tags: - hed-to-reef - image-to-image - cyclegan - hed-to-anything --- # CycleGAN_GradientMagnitude2CoralReef Model This model transforms Gradient Magnitude maps into coral reef style images, and also transforms coral reef style images into estimated Gradient Magnitude maps using the CycleGAN architecture via junyanz's [pytorch-CycleGAN-and-pix2pix](https://github.com/junyanz/pytorch-CycleGAN-and-pix2pix).
depth map robot-style image
robot-style image depth map
## Model Description - This model was trained on coral reef images generated with SDXL, and their associated HED maps, taken with pytorch-hed: [Depth2RobotsV2_Annotations](https://huggingface.co/datasets/Borcherding/GradientMagnitude2CoralReef_Annotations) - using CycleGAN architecture - Training notebooks and dataset genertors can be found in the src folder, and can also be found in the github repo !(Leoleojames1/CycleGANControlNet2Anything)[https://github.com/Leoleojames1/CycleGANControlNet2Anything] - It supports bidirectional transformation: - Gradient Magnitude map → Coral reef-style imagery - Robot-style imagery → Depth map - The model uses a ResNet-based generator with residual blocks ## Installation ```bash # Clone the repository git clone https://huggingface.co/Borcherding/CycleGAN_GradientMagnitude2CoralReef_Blend cd CycleGAN_GradientMagnitude2CoralReef_Blend # Install dependencies pip install torch torchvision gradio pyvirtualcam ``` ## Usage Options ### Option 1: Simple Test Interface Run the simple test interface to quickly try out the model: ```bash python cycleGANtest.py ``` This launches a Gradio interface where you can: - Upload an image - Select conversion direction (Depth to Image or Image to Depth) - Transform the image with a single click ### Option 2: Webcam Integration with Depth Estimation For a more advanced setup that includes real-time webcam processing with Depth Anything V2: ```bash # Set the path to Depth Anything V2 export DEPTH_ANYTHING_V2_PATH=/path/to/depth-anything-v2 # Run the integrated application python discordDepth2AnythingGAN.py ``` This launches a Gradio interface that allows you to: - Capture webcam input - Generate depth maps using Depth Anything V2 - Apply winter-themed colormap to depth maps - Apply CycleGAN transformation in either direction - Output to a virtual camera for use in video conferencing or streaming ## Using the Model Programmatically ```python import torch import numpy as np import torchvision.transforms as transforms from PIL import Image from huggingface_hub import hf_hub_download # Define the Generator architecture (as shown in the provided code) class ResidualBlock(nn.Module): def __init__(self, channels): super(ResidualBlock, self).__init__() self.conv_block = nn.Sequential( nn.ReflectionPad2d(1), nn.Conv2d(channels, channels, 3), nn.InstanceNorm2d(channels), nn.ReLU(inplace=True), nn.ReflectionPad2d(1), nn.Conv2d(channels, channels, 3), nn.InstanceNorm2d(channels) ) def forward(self, x): return x + self.conv_block(x) class Generator(nn.Module): def __init__(self, input_channels=3, output_channels=3, n_residual_blocks=9): super(Generator, self).__init__() # Initial convolution model = [ nn.ReflectionPad2d(3), nn.Conv2d(input_channels, 64, 7), nn.InstanceNorm2d(64), nn.ReLU(inplace=True) ] # Downsampling in_features = 64 out_features = in_features * 2 for _ in range(2): model += [ nn.Conv2d(in_features, out_features, 3, stride=2, padding=1), nn.InstanceNorm2d(out_features), nn.ReLU(inplace=True) ] in_features = out_features out_features = in_features * 2 # Residual blocks for _ in range(n_residual_blocks): model += [ResidualBlock(in_features)] # Upsampling out_features = in_features // 2 for _ in range(2): model += [ nn.ConvTranspose2d(in_features, out_features, 3, stride=2, padding=1, output_padding=1), nn.InstanceNorm2d(out_features), nn.ReLU(inplace=True) ] in_features = out_features out_features = in_features // 2 # Output layer model += [ nn.ReflectionPad2d(3), nn.Conv2d(64, output_channels, 7), nn.Tanh() ] self.model = nn.Sequential(*model) def forward(self, x): return self.model(x) # Download the model def download_model(direction="depth2image"): if direction == "depth2image": filename = "latest_net_G_A.pth" else: # "image2depth" filename = "latest_net_G_B.pth" model_path = hf_hub_download( repo_id="Borcherding/CycleGAN_GradientMagnitude2CoralReef_Blend", filename=filename ) return model_path # Image preprocessing def preprocess_image(image): """ Preprocess image for model input Args: image: PIL Image or numpy array Returns: torch.Tensor: Normalized tensor ready for model input """ if isinstance(image, np.ndarray): image = Image.fromarray(image.astype('uint8'), 'RGB') transform = transforms.Compose([ transforms.Resize(256), transforms.ToTensor(), transforms.Normalize(mean=[0.5, 0.5, 0.5], std=[0.5, 0.5, 0.5]) ]) return transform(image).unsqueeze(0) # Image postprocessing def postprocess_image(tensor): """ Convert model output tensor to numpy image Args: tensor: Model output tensor Returns: numpy.ndarray: RGB image array (0-255) """ tensor = tensor.squeeze(0).cpu() tensor = (tensor + 1) / 2 tensor = tensor.clamp(0, 1) tensor = tensor.permute(1, 2, 0).numpy() return (tensor * 255).astype(np.uint8) # Example usage def transform_image(input_image_path, direction="depth2image"): """ Transform an image using the Depth2Robot model Args: input_image_path: Path to input image direction: "depth2image" or "image2depth" Returns: numpy.ndarray: Transformed image """ # Load model model_path = download_model(direction) model = Generator() model.load_state_dict(torch.load(model_path, map_location='cpu'), strict=False) model.eval() # Load and preprocess image input_image = Image.open(input_image_path).convert('RGB') input_tensor = preprocess_image(input_image) # Generate output with torch.no_grad(): output_tensor = model(input_tensor) # Postprocess output output_image = postprocess_image(output_tensor) return output_image ``` ## Model Checkpoints The model checkpoints are available on Hugging Face: - Repository: [Borcherding/Depth2RobotsV2_Annotations](https://huggingface.co/datasets/Borcherding/GradientMagnitude2CoralReef_Annotations) - Files: - `latest_net_G_A.pth` - Generator for Depth to Robot Image transformation - `latest_net_G_B.pth` - Generator for Robot Image to Depth transformation ## Gradient Magnitude Calculations Our Gradient Magnitude functions reference [DCurro/CannyEdgePytorch](https://github.com/DCurro/CannyEdgePytorch/blob/master/gradient_magnitude.png). ## Requirements - Python 3.7+ - PyTorch 1.7+ - torchvision - gradio - pyvirtualcam (for webcam integration) - OpenCV (cv2) - Depth Anything V2 (for integrated application) ## License [Insert your license information here] ## Acknowledgments - This model uses CycleGAN architecture from the paper [Unpaired Image-to-Image Translation using Cycle-Consistent Adversarial Networks](https://arxiv.org/abs/1703.10593) by Zhu et al. - The implementation is based on [junyanz/pytorch-CycleGAN-and-pix2pix](https://github.com/junyanz/pytorch-CycleGAN-and-pix2pix) - Integrated application leverages Depth Anything V2 for depth estimation
